1010738543 supersedes older part numbers: 1010692594, 1010677668, 1010689119, 1010738535, 1010698878, 1381158612

Metabo 1010738543 — Saw blade guard with integrated suction port. Replacement guard designed for the Metabo TKHS 315 table-saw family; it covers the rotating blade, mounts to the machine’s guard/riving-knife assembly and provides an integrated dust-extraction connection so debris is pulled away at the cut.

Key details:

- Part number: 1010738543 (listed in Metabo spare-parts diagrams as "SAW BLADE GUARD W/SUCTION PORT").

- Intended for use with 315 mm table-saw blades (315 × 30 mm bore) as fitted to the TKHS 315 series.

- Integrated suction/dust port mates with the TKHS dust-extraction arrangement (the TKHS parts lists show the corrugated extraction hose for these machines at ~36.2 mm), so it connects to the machine’s dust-extraction hose or a compatible shop-vac hose.

- Sold as the direct Metabo replacement guard used in the parts breakdowns for the TKHS 315 machines (fits the guard carrier / riving-knife assembly shown in the Metabo diagrams).

Example compatible Metabo models (from Metabo parts diagrams and parts listings):

- TKHS 315C series (examples: 0103152000, 0103152038, 0103152150).

- TKHS 315M series (examples: 0103153038, 0103153039, 0103153100, 0103153021, 0103153200, 0103153300).

If your TKHS 315 table saw uses a 315×30 mm blade and the factory guard/riving-knife mount, this is the genuine Metabo replacement designed to restore blade protection and dust extraction functionality.
